Troubleshooting SSH Access Issues to a VM on GCP

Table of Contents

1. Problem Statement: VM Not Accessible Over SSH

2. Solution: Enabling Serial Console Login

3. Why This Solution is Best

4. Other Solutions to Restore SSH Access

   Verify and Update Firewall Rules

   Add or Update SSH Keys in GCP Metadata

   Use the VM Repair Tool

5. Conclusion




1. Problem Statement: VM Not Accessible Over SSH

If you're unable to access a Virtual Machine (VM) over SSH via the Google Cloud Platform (GCP) console, it can be a frustrating issue that prevents you from managing your instance. SSH access issues can be caused by several factors, such as misconfigured firewall settings, incorrect SSH keys, or network connectivity problems. Regardless of the root cause, it's essential to restore access to the VM as quickly as possible, especially if the VM is running critical applications.

2. Solution: Enabling Serial Console Login

Enable Serial Console Access

One of the most effective ways to troubleshoot and resolve SSH issues is by enabling serial console login on your VM. The serial console allows you to directly connect to the VM instance, bypassing SSH or network configuration issues. This method provides an independent connection to the VM, enabling you to diagnose problems even if SSH access is unavailable.

Steps to Enable Serial Console:

1. Go to the Google Cloud Console: Navigate to Compute Engine > VM Instances.

2. Select the Instance: Choose the VM that is currently not accessible via SSH.

3. Access Serial Console: Under the "Serial Port" section of the VM instance details, click on the "Connect to serial console" option. This will establish a connection to the VM's serial console.

4. Diagnose and Resolve Issues: Once connected, you can run diagnostics, check logs, fix any configuration issues, or restart services that may be causing SSH failures.




This solution bypasses the need for network-related configurations and provides a direct way to access the VM to resolve any issues.

3. Why This Solution is Best

The serial console login is the best solution because it doesn’t rely on SSH or network configurations. It provides direct access to the VM, ensuring that you can resolve any underlying issues without needing to adjust firewall settings, SSH keys, or other network-related configurations. It's a reliable method to quickly identify misconfigurations or connectivity problems that are preventing SSH access. Moreover, serial console access does not require additional resource setup, making it a straightforward solution.

4. Other Solutions to Restore SSH Access

If enabling serial console login doesn't resolve the issue or you're looking for alternative ways to fix the problem, here are other solutions to consider:

Verify and Update Firewall Rules

A common reason for SSH access issues is incorrectly configured firewall rules that block incoming traffic on port 22, which is required for SSH.

Steps to Fix Firewall Rules:

1. Check Existing Firewall Rules: Go to VPC Network > Firewall Rules in the GCP Console.

2. Ensure Port 22 is Open: Verify if there’s an existing rule that allows inbound traffic on port 22 (SSH). If not, create a new firewall rule to allow SSH traffic:

   bash

   Copy code

   gcloud compute firewall-rules create allow-ssh --allow tcp:22 --source-ranges <source-ip-range>




This ensures that SSH access is allowed from trusted IP addresses, resolving any firewall-related access issues.

Add or Update SSH Keys in GCP Metadata

If your SSH keys are outdated or missing, you may not be able to connect to the VM via SSH. Adding or updating SSH keys in the GCP metadata can restore access.

Steps to Add or Update SSH Keys:

1. Go to Compute Engine > Metadata in the GCP Console.

2. Check SSH Keys: Under the SSH Keys tab, verify that your SSH key is correctly listed.

3. Add New SSH Key (If Necessary): If the key is missing or you need to update it, you can add your new SSH key:

   bash

   Copy code

   gcloud compute instances add-metadata <instance-name> --metadata ssh-keys="<your-ssh-key>"




This ensures that the correct SSH key is associated with the VM, restoring SSH access securely.

Use the VM Repair Tool

If none of the above solutions work, you can use the VM repair tool to reset or repair the VM instance. This tool can help fix issues with the operating system or the VM's state that might be preventing SSH access.

Steps to Use the VM Repair Tool:

1. Go to Compute Engine > VM Instances in the GCP Console.

2. Select the Affected VM: Choose the instance that is experiencing SSH access issues.

3. Repair the Instance: Use the "Repair" option to reset the VM, which can help restore connectivity and fix any underlying system-level issues.




The repair tool essentially reboots the VM and can resolve system-level misconfigurations that may have caused the SSH issue.

5. Conclusion

When a VM on GCP is not accessible over SSH, the best solution is to enable serial console login, as it bypasses SSH and network configurations to allow direct access. This solution provides a quick and effective way to troubleshoot and resolve issues. However, if additional troubleshooting is required, solutions like verifying firewall rules, updating SSH keys, or using the VM repair tool can also help restore access. By following these steps, you can regain SSH access to your VM and resolve any connectivity issues efficiently.
